▼Size: 2.5"

▼Window:

• Glass
• Silicone rubber O-ring sealed

▼Pressure connection: copper alloy, 1/4” NPT

▼Pressure range: 0…1 to 16 bar

• Min.: -50°C
• Max.: 160°C

▼Ambient temperature: -40°C to +60°C

▼Fluid temperature: Equal to the specified temperature measurement range

▼Temperature error: Every ±8 °C max. error: ±0.3 % F.S

▼Protection level: IP 65

▼Ring: Stainless steel

▼Case: SS 304

▼Pointer: Aluminum with black enamel

▼Dial face: Blue and black scale

▼Measuring elements:

• Bourdon tube
• Material: copper alloy

▼Movement: Copper alloy

▼Accuracy:

• Pressure:±1.6%
• Temperature:±1℃

▼Operating pressure

• Stabilization: 3/4* full scale
• Fluctuation: 2/3* full scale
• Impulse: 1* full scale
