Đồng Hồ Áp Suất KINS Magnetic 2010 Differential Pressure Gauge With Switch

• Summary
  • This gauge has a structure like MAGNETIC 2000 MODEL with contact signal Therefore, it produces a warning signal by sending it to buzzer, bell, polot-lamp.
• Diameter 100mm
• Accuracy ±2.0% of Full Scale

• Scale Range
• -0.25~0.25kPa ~ -10~10kPa, 0~50kPa
  (※ 1 kPa = 101.9716 mm H₂O)
• Working Pressure
• Static pressure: 75% of Full Scale
• Fluctuating pressure: 60% of Full Scale
• Working Temperature
• Ambient: - 10 ~ 60 ℃
• Case & Cover Aluminum (Hammer tone coating)
• Connection PT ↔ 1/8(Female)
• Type BD-Type (Panel attachment type-Bracket)
• Window Poly Carbonate
• Pointer
• Aluminum
• Pointer: Red color, Green color
• Dial
• Aluminum
• White coating
• Black gradations and characters

• Element Silicon Rubber, NBR
• Base Pressure 0.1 MPa
• Switch
• Type: 2-SPDT (2 contact)
• Capacity of switch: 220V AC 10A
• Set up method: exterior
• Dead band: below 4 % of the total range
