Đồng Hồ Áp Suất KINS SD-3020 - Euro Pressure Gauge

• Summary This instrument has a micro switch which produces a contact signal when there is an increase or decrease of temperature by controlling the setting temperature outside.
• Accuracy ±2.0% of Full Scale
• Scale Range -30℃ ~ 650℃
• Common Temperature 75% of Full Scale
• Explosion-Protected Ex d IIC T4
• Case & Cover
  • Aluminum (Hammer tone coating)
  • Explosion-protected type (Ex d IIC T4)
• Connection
  • STS 304, 316
  • PF, PT, NPT ↔ 1/2(Standard)
• Window
  • Tempered safety glass
  • Laminated safety glass
• Stem
  • STS 304, STS 316
  • Out Dia.: Ø 8, Ø 10, Ø 12mm
• Dial
  • Aluminum
  • Color of white
  • Black gradation and characters
• Pointer
  • Aluminum
  • Black coating
• Bourdon Tube STS 304
• Contact rating
  • AC 125V 0.5A / 250V 0.25A
  • DC 24V 0.25A
• Contact Form
  • Micro Contact Type
  • SPDT * 1, SPDT * 2, DPDT * 1
    (High, Low, High & High High & Low, Low & Low)
• Well
  • STS 304, 316
  • Titanium, Monel, Hastelloy, Teflon Lining, Glass Lining
