Đồng Hồ Áp Suất KINS SS-3012 Series 200mm

• Summary
  • This gauge is the most widely used pressure gauge. It has high durability by doing special process in bourdon tube.
• Diameter 200mm
• Accuracy

• 40mm: ±3.0% of Full Scale
• 50mm: ±3.0% or ±1.5% of Full Scale
• 60, 75, 100, 150mm: ±1.5% of Full Scale
• Working Pressure
• Static pressure: 75% of Full Scale
• Fluctuating pressure: 60% of Full Scale
• Working Temperature
• Ambient: - 20 ~ 65 ℃
• Fluid: - 20 ~ 40 ℃
• Case
• Steel (SPCD)
• Black coating
• Cover
• Steel (SPCD)
• Black coating
• Connection
• Brass(C3604BE)
• PF ↔ 3/8
• Window General glass
• Type
• B-Type (Surface type)
• Pointer
• Aluminum
• Black coating
• Dial
• Aluminum
• White color coating
• Black (MPa), red (bar) gradations and characters

• Element
• Brass (C2700T)
• C type bourdon tube
• Movement Brass
• Option
• Throttles
• Accessories
