Đồng Hồ Áp Suất KINS SS-3020 Special Pressure Gauge

• Summary
  • This gauge has high corrosive resistance and its properly built to measure fluid pressure which can withstand outside condition change. It has high accuracy because its connecting part is made of STS.
• Diameter 40, 50, 60, 75, 100, 150mm
• Accuracy

• 40mm: ±3% of Full Scale
• 50mm: ±1.5% of Full Scale
• 100, 150mm: ±1.0% of Full Scale
• Working Pressure
• Static pressure: 75% of Full Scale
• Fluctuating pressure: 60% of Full Scale
• Working Temperature
• Ambient: - 20 ~ 65 ℃
• Fluid: - 20 ~ 80 ℃
• Degree of Protection IP 67
• Case STS 304
• Cover STS 304
• Connection
• STS 316
• PF, PT, NPT ↔ 1/4, 3/8, ½
• UNF 7/16
• Window Tempered safety glass, Laminated safety glass
• Type
• A-type (Rimeless type)
• B-type (Surface type)
• D-type (Flush mounting type
• BD-type (Panel attachment type)
• Pointer
• Aluminum
• Black coating
• Dial
• Aluminum
• White color coating
• Black (MPa), red (bar) gradations and characters

• Element
• STS 304, STS 316
• C type bourdon tube, helical type bourdon tube
• Movement STS 304
• Option
• Blow out protection on the Top Rubber Disc
• Bracket
• Throttles
• Accessories
