Thông Số Kỹ Thuật

• Shaft diameter: d1 = 35 … 140 (500) mm (1.38” … 5.51” (19.68”))
• Axial offset shaft / housing:
  • d1 = 35 … 60 mm (1.38” … 2.36”): max. ±1.5 mm (0.059”)
  • d1 >60 mm (2.36”): max. ±2.0 mm (0.079”)
• Radial offset shaft/housing: max. ±0.3 mm (0.012”)
• Pressure:
  • p1 = vacuum … 14 (23) bar (203 (334) PSI)
  • p3 = max. 16 (25) bar (232 (363) PSI)
  • Δ p3-p1 = 2 …10 bar (29 …145 PSI), higher Δp on request
• Temperature: t1 = -20 °C … +200 (300) °C (-4 °F … +392 (572) °F)
• Sliding velocity: vg = max. 10 (20) m/s (33 (66) ft/s)

  For applications beyond this range and for values in brackets, please inquire.

  ! It should be noted that the extremal values of each operating parameter cannot be applied at the same time because of their interaction.
